B82725J2102N020
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Radial 4 e3 Common Mode Choke 1A 1.05Ohm 10kHz 40.4mm
PDF
/
Inventory: 1765
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 21.5mm
Length 40.4mm
Height 40mm
Technical
DC Current 1A
Inductance-Nom (L) 68000 μH
DC Resistance (DCR) - Parallel 1.05Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 1A
Test Frequency 10kHz
Inductance 68 mH
Lead Diameter 1 mm
Lead Pitch 17.5mm
Military Standard Not
Construction Rectangular
Depth 21.5mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination Radial
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
