B82725A2202N001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) 4 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 2A 350mOhm 10kHz 44mm
PDF
/
Buying Options
Total Price: USD $5.73
Unit Price: USD $5.7288
≥1 USD $5.7288
≥10 USD $4.63848
≥100 USD $4.123328
≥500 USD $3.89422
≥1000 USD $3.608
≥3000 USD $3.550721
Inventory: 307
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Through Hole
Terminal Shape FLAT
Number of Pins 4
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Box
Tolerance 30%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
ECCN Code EAR99
Resistance 350mOhm
Terminal Finish Tin (Sn)
Packing Method Tray
Shielding Unshielded
Number of Functions 2
Depth 42.4mm
Construction Rectangular
Military Standard Not
Voltage - Rated AC 250V
Lead Pitch 15mm
Operating Temperature (Max) 125°C
Inductance 18 mH
Test Frequency 10kHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
Rated Current-Max 2A
Inductance Tolerance 30%
Inductance-Nom (L) 18000 μH
DC Current 2A
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
Dimensions
Length 44mm
Width 44mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
