B82724J2402N001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) 2 e3 Common Mode Choke 4A 65mOhm 10kHz 31.3mm
PDF
/
Buying Options
Total Price: USD $3.15
Unit Price: USD $3.1504
≥1 USD $3.1504
≥10 USD $2.63472
≥100 USD $2.405216
≥500 USD $2.06162
≥1000 USD $1.889914
≥3000 USD $1.832635
Inventory: 748
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 15mm
Length 31.3mm
Height 33.2mm
Technical
DC Current 4A
Inductance-Nom (L) 3300 μH
Inductance Tolerance 30%
DC Resistance (DCR) - Parallel 65mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 4A
Test Frequency 10kHz
Inductance 3.3 mH
Lead Diameter 700 μm
Lead Pitch 12.5mm
Voltage - Rated AC 250V
Military Standard Not
Construction Rectangular
Depth 15mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
Resistance 66mOhm
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 31.000005g
Number of Pins 4
Terminal Shape WIRE
Mount Radial
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
