B82724J2142N021
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) - with Nickel (Ni) barrier 2 e3 Common Mode Choke 1.4A 420mOhm 10kHz 31.3mm
PDF
/
Buying Options
Total Price: USD $3.67
Unit Price: USD $3.668141
≥1 USD $3.668141
≥10 USD $3.460504
≥100 USD $3.264634
≥500 USD $3.07984
≥1000 USD $2.905513
Inventory: 1419
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 18.5mm
Length 31.3mm
Height 33.2mm
Technical
DC Current 1.4A
Inductance-Nom (L) 37000 μH
DC Resistance (DCR) - Parallel 420mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Test Frequency 10kHz
Inductance 37 mH
Lead Diameter 700 μm
Lead Pitch 15mm
Military Standard Not
Current Rating 1.4A
Construction Rectangular
Depth 15mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Termination Radial
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Packaging Box
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 31.000005g
Terminal Shape WIRE
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
