B82724J2102N1

EPCOS
RoHS
/
Package Radial
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 33mH 10kHz 1A 750mOhm DCR Thru-Hole Box
PDF
/
Inventory: 993
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Width 18.4912mm
Length 31.3mm
Height 33.2mm

Technical

Number of Lines 2
Series Resistance 810mOhm
DC Current 1A
Inductance-Nom (L) 0.033 μH
DC Resistance (DCR) - Parallel 750mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application FILTER CHOKE
Max DC Current 1A
Current 1A
Test Frequency 10kHz
Inductance 33 mH
Military Standard Not
Current Rating 1A
Depth 15mm
Number of Functions 2
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 31.000005g
Number of Pins 4
Terminal Shape WIRE
Package / Case Radial
Mount Through Hole
