B82724B2152N020
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) - with Nickel (Ni) barrier 2 INDUCTANCE IS MEASURED AT 0.1MILLI AMPERE Common Mode Choke 1.5A 530mOhm 10kHz 33.6mm
PDF
/
Buying Options
Total Price: USD $5.41
Unit Price: USD $5.413332
≥1 USD $5.413332
≥10 USD $5.106916
≥100 USD $4.817847
≥500 USD $4.545138
≥1000 USD $4.287868
Inventory: 1117
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Through Hole
Terminal Shape WIRE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Box
Tolerance 30%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
Termination Radial
ECCN Code EAR99
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8504.50.80.00
Packing Method Tray
Shielding Unshielded
Number of Functions 2
Depth 32.6mm
Construction Rectangular
Current Rating 1.5A
Military Standard Not
Operating Temperature (Max) 125°C
Operating Temperature (Min) -40°C
Lead Diameter 0.7 mm
Inductance 49 mH
Test Frequency 10kHz
Max DC Current 1.5A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 530mOhm
Inductance-Nom (L) 49000 μH
DC Current 1.5A
Special Feature INDUCTANCE IS MEASURED AT 0.1 MILLI AMPERE
Dimensions
Height 25mm
Length 33.6mm
Width 32.6mm
Compliance
RoHS Status RoHS Compliant
