B82724A2501N001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) 2 e3 Common Mode Choke 500mA 2.3Ohm 10kHz 31.3mm
PDF
/
Inventory: 9639
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 18.5mm
Length 31.3mm
Height 33.2mm
Technical
DC Current 500mA
Inductance-Nom (L) 82000 μH
Inductance Tolerance 30%
DC Resistance (DCR) - Parallel 2.3Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 500mA
Test Frequency 10kHz
Inductance 82 mH
Lead Diameter 700 μm
Lead Pitch 15mm
Military Standard Not
Current Rating 500mA
Construction Rectangular
Depth 32.6mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
Resistance 2.3Ohm
ECCN Code EAR99
Termination Radial
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 31.000005g
Number of Pins 4
Terminal Shape WIRE
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
