B82723A2102N001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray FLAT 2 INDUCTANCE IS MEASURED AT 0.1MILLI AMPERE Common Mode Choke 1A 750mOhm 10kHz 28mm
PDF
/
Buying Options
Total Price: USD $2.76
Unit Price: USD $2.7632
≥1 USD $2.7632
≥10 USD $2.31088
≥100 USD $2.109888
≥500 USD $1.80862
≥1000 USD $1.657814
≥3000 USD $1.607566
Inventory: 294
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 28mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 MILLI AMPERE
DC Current 1A
Inductance-Nom (L) 27000 μH
Inductance Tolerance 30%
Rated Current-Max 1A
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Test Frequency 10kHz
Inductance 27 mH
Operating Temperature (Max) 125°C
Lead Pitch 25mm
Military Standard Not
Current Rating 1A
Construction Rectangular
Depth 27mm
Number of Functions 2
Shielding NO
Packing Method Tray
Terminal Finish Tin (Sn)
Resistance 750mOhm
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Packaging Box
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 4
Terminal Shape FLAT
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
