B82722J2501N021
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) - with Nickel (Ni) barrier 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 500mA 1.12Ohm 10kHz 23.2918mm
PDF
/
Inventory: 2692
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 16.1036mm
Length 23.2918mm
Height 25.4mm
Technical
Current Rating (Max) 500mA
Number of Lines 2
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
DC Current 500mA
Inductance-Nom (L) 39000 μH
DC Resistance (DCR) - Parallel 1.12Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Test Frequency 10kHz
Inductance 39 mH
Lead Diameter 0.7 mm
Approval Agency ENEC, UR, VDE
Voltage - Rated AC 250V
Military Standard Not
Construction Rectangular
Depth 16.1mm
Number of Functions 2
Shielding NO
Packing Method Tray
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
