B82722J2301N002
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) - with Nickel (Ni) barrier 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 300mA 2.5Ohm 10kHz 23.2918mm
PDF
/
Buying Options
Total Price: USD $2.33
Unit Price: USD $2.332
≥1 USD $2.332
≥10 USD $1.95272
≥100 USD $1.783232
≥500 USD $1.52834
≥1000 USD $1.401074
≥3000 USD $1.35857
Inventory: 582
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 16.1036mm
Length 23.2918mm
Height 25.4mm
Technical
Current Rating (Max) 300mA
Number of Lines 2
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
DC Current 300mA
Inductance-Nom (L) 68000 μH
DC Resistance (DCR) - Parallel 2.5Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Test Frequency 10kHz
Inductance 68 mH
Lead Diameter 0.7 mm
Approval Agency ENEC, UR, VDE
Voltage - Rated AC 250V
Military Standard Not
Construction Rectangular
Depth 16.1mm
Number of Functions 2
Shielding NO
Packing Method Tray
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
