B82722J2252N001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray DUAL IN-LINE 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 2.5A 80mOhm 0.01MHz 23.2918mm
PDF
/
Inventory: 5659
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 16.1036mm
Length 23.2918mm
Height 25.4mm
Technical
Current Rating (Max) 2.5A
Number of Lines 2
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
Inductance-Nom (L) 1700 μH
DC Resistance (DCR) - Parallel 80mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Test Frequency 0.01MHz
Lead Diameter 0.7 mm
Approval Agency ENEC, UR, VDE
Voltage - Rated AC 250V
Reach Compliance Code unknown
Construction Rectangular
Number of Functions 2
Shielding NO
Packing Method Tray
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Tolerance 30%
Physical
Core Material FERRITE
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WIRE
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
