B82722J2152N020
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray DUAL IN-LINE 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 1.5A 240mOhm 0.01MHz 23.2918mm
PDF
/
Buying Options
Total Price: USD $2.33
Unit Price: USD $2.332
≥1 USD $2.332
≥10 USD $1.95272
≥100 USD $1.783232
≥500 USD $1.52834
≥1000 USD $1.401074
≥3000 USD $1.35857
Inventory: 220
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Mount Through Hole
Terminal Shape WIRE
Shape/Size Description RECTANGULAR PACKAGE
Core Material FERRITE
Technical
Tolerance 30%
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method Tray
Shielding NO
Number of Functions 2
Construction Rectangular
Reach Compliance Code unknown
Voltage - Rated AC 250V
Approval Agency ENEC, UR, VDE
Lead Diameter 0.7 mm
Test Frequency 0.01MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 240mOhm
Inductance-Nom (L) 10000 μH
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
Number of Lines 2
Current Rating (Max) 1.5A
Dimensions
Height 25.4mm
Length 23.2918mm
Width 16.1036mm
Compliance
RoHS Status RoHS Compliant
