B82722J2102N020
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray DUAL IN-LINE 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 1A 540mOhm 0.01MHz 23.2918mm
PDF
/
Inventory: 9573
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Mount Through Hole
Terminal Shape WIRE
Shape/Size Description RECTANGULAR PACKAGE
Core Material FERRITE
Technical
Tolerance 30%
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method Tray
Shielding NO
Number of Functions 2
Construction Rectangular
Reach Compliance Code unknown
Voltage - Rated AC 250V
Approval Agency ENEC, UR, VDE
Lead Diameter 0.7 mm
Test Frequency 0.01MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 540mOhm
Inductance-Nom (L) 15000 μH
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
Number of Lines 2
Current Rating (Max) 1A
Dimensions
Height 25.4mm
Length 23.2918mm
Width 16.1036mm
Compliance
RoHS Status RoHS Compliant
