B82722J2102N001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 1A 480mOhm 10kHz 23.3mm
PDF
/
Buying Options
Total Price: USD $1.84
Unit Price: USD $1.8392
≥1 USD $1.8392
≥10 USD $1.54088
≥100 USD $1.406592
≥500 USD $1.20582
≥1000 USD $1.179314
Inventory: 4990
Minimum: 1
-
+
Technical Details
Physical
Terminal Shape WIRE
Number of Pins 4
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Mount Radial
Technical
Packaging Box
Tolerance 30%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
ECCN Code EAR99
Resistance 480mOhm
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
DC Current 1A
Inductance-Nom (L) 10000 μH
Inductance Tolerance 30%
DC Resistance (DCR) - Parallel 480mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 1A
Test Frequency 10kHz
Inductance 10 mH
Lead Diameter 700 μm
Lead Pitch 10mm
Voltage - Rated AC 250V
Military Standard Not
Construction Rectangular
Depth 16.1mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 16.1mm
Length 23.3mm
Height 25.4mm
