B82722A2202N020
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box DUAL IN-LINE 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 2A 130mOhm 10kHz 22.7mm
PDF
/
Buying Options
Total Price: USD $2.33
Unit Price: USD $2.332
≥1 USD $2.332
≥10 USD $1.95272
≥100 USD $1.783232
≥500 USD $1.52834
≥1000 USD $1.401074
≥3000 USD $1.35857
Inventory: 693
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 22.3mm
Length 22.7mm
Height 13.3mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
DC Current 2A
Inductance-Nom (L) 4200 μH
DC Resistance (DCR) - Parallel 130mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 2A
Test Frequency 10kHz
Inductance 4.2 mH
Lead Diameter 700 μm
Lead Pitch 20mm
Military Standard Not
Construction Rectangular
Depth 22.3mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Termination Radial
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Packaging Box
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
