B82721K2202N001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 2A 80mOhm 100kHz 18.2mm
PDF
/
Buying Options
Total Price: USD $2.29
Unit Price: USD $2.288
≥1 USD $2.288
≥10 USD $1.94744
≥100 USD $1.794496
≥500 USD $1.60358
≥1000 USD $1.336394
≥3000 USD $1.298194
Inventory: 1894
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Radial
Terminal Shape WIRE
Number of Pins 4
Weight 5.000005g
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Box
Tolerance 30%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
ECCN Code EAR99
Resistance 80mOhm
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Packing Method Tray
Orientation Vertical
Shielding NO
Number of Functions 2
Depth 13.2mm
Construction Rectangular
Current Rating 2A
Military Standard Not
Lead Pitch 15mm
Lead Diameter 700 μm
Inductance 1 mH
Test Frequency 100kHz
Max DC Current 2A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 80mOhm
Inductance Tolerance 30%
Inductance-Nom (L) 1000 μH
DC Current 2A
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
Dimensions
Height 20.3mm
Length 18.2mm
Width 13.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
