B82721A2401N021
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box DUAL IN-LINE 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 400mA 1.7Ohm 10kHz 17.9mm
PDF
/
Buying Options
Total Price: USD $2.29
Unit Price: USD $2.288
≥1 USD $2.288
≥10 USD $1.94744
≥100 USD $1.794496
≥500 USD $1.60358
≥1000 USD $1.336394
≥3000 USD $1.298194
Inventory: 184
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Contact Plating Tin
Mount Through Hole
Terminal Shape WIRE
Number of Pins 4
Weight 5.000005g
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Box
Tolerance 30%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
Termination Radial
ECCN Code EAR99
Resistance 1.7Ohm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Packing Method Tray
Shielding NO
Number of Functions 2
Depth 17.3mm
Construction Rectangular
Current Rating 400mA
Military Standard Not
Lead Pitch 15mm
Lead Diameter 0.7 mm
Inductance 27 mH
Test Frequency 10kHz
Max DC Current 400mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 1.7Ohm
Inductance Tolerance 30%
Inductance-Nom (L) 27000 μH
DC Current 400mA
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
Dimensions
Height 12.6mm
Length 17.9mm
Width 17.3mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
