B82720K2601N040
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Bulk Tin (Sn) 2 INDUCTANCE IS MEASURED AT 0.1MILLI AMPERE Common Mode Choke 600mA 400mOhm 10kHz 13.3mm
PDF
/
Buying Options
Total Price: USD $1.91
Unit Price: USD $1.9096
≥1 USD $1.9096
≥10 USD $1.62096
≥100 USD $1.49424
≥500 USD $1.33518
≥1000 USD $1.112672
≥3000 USD $1.080904
Inventory: 26
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Through Hole
Terminal Shape FLAT
Number of Pins 4
Weight 2.500003g
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Tolerance 10%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
Termination Radial
ECCN Code EAR99
Resistance 400mOhm
Terminal Finish Tin (Sn)
Packing Method Bulk
Shielding NO
Number of Functions 2
Depth 9.5mm
Construction Rectangular
Current Rating 600mA
Military Standard Not
Operating Temperature (Max) 125°C
Inductance 4.4 mH
Test Frequency 10kHz
Max DC Current 600mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 400mOhm
Inductance Tolerance -30%
Inductance-Nom (L) 4400 μH
DC Current 600mA
Special Feature INDUCTANCE IS MEASURED AT 0.1 MILLI AMPERE
Dimensions
Height 14.3mm
Length 13.3mm
Width 9.5mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
