B82720K2202N40

EPCOS
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 1.1mH 10kHz 2A 65mOhm DCR Thru-Hole Box
PDF
/
Inventory: 4670
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 9.4996mm
Length 13mm
Height 13.9954mm

Technical

Current Rating (Max) 2A
Number of Lines 2
Inductance-Nom (L) 1100 μH
DC Resistance (DCR) - Parallel 65mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Radial
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 1A
Current 2A
Test Frequency 0.01MHz
Inductance 1.1 mH
Approval Agency ENEC, UR, VDE
Voltage - Rated AC 250V
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%

Physical

Core Material FERRITE
Shape/Size Description RECTANGULAR PACKAGE
Weight 2.500003g
Terminal Shape WIRE
Mount Through Hole
Contact Plating Tin
