B82720H0015A016
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box DUAL IN-LINE 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT Common Mode Choke 700mA 500mOhm 10kHz 13mm
PDF
/
Buying Options
Total Price: USD $22.63
Unit Price: USD $22.63375
≥1 USD $22.63375
≥10 USD $18.57155
≥100 USD $17.9911
≥500 USD $17.41065
≥1000 USD $16.8302
Inventory: 1584
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Contact Plating Tin
Mount Through Hole
Terminal Shape FLAT
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Box
Tolerance 50%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
Termination Radial
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Shielding Unshielded
Number of Functions 2
Depth 9.5mm
Military Standard Not
Lead Pitch 10mm
Lead Diameter 500 μm
Inductance 4.7 mH
Test Frequency 10kHz
Max DC Current 700mA
Terminal Placement DUAL IN-LINE
Lead/Base Style PC Pin
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 500mOhm
Inductance-Nom (L) 4700 μH
DC Current 700mA
Special Feature INDUCTANCE IS MEASURED AT 0.1 MA DC CURRENT
Dimensions
Height 14mm
Length 13mm
Width 9.5mm
Compliance
RoHS Status RoHS Compliant
