B82615B2502M001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) 1 INDUCTANCE IS MEASURED AT 0.1MILLI AMPERE Common Mode Choke 5A 1.5Ohm 44mm 1mH
PDF
/
Buying Options
Total Price: USD $7.05
Unit Price: USD $7.0488
≥1 USD $7.0488
≥10 USD $5.79304
≥100 USD $5.323648
≥500 USD $5.01028
≥1000 USD $4.77554
≥3000 USD $4.69722
Inventory: 178
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 42.4mm
Length 44mm
Height 30mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 MILLI AMPERE
DC Current 5A
Inductance-Nom (L) 1000 μH
Inductance Tolerance 20%
DC Resistance (DCR) - Parallel 1.5Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 5A
Inductance 1 mH
Operating Temperature (Max) 125°C
Lead Pitch 40mm
Military Standard Not
Current Rating 5A
Construction Rectangular
Depth 42.4mm
Number of Functions 1
Shielding Unshielded
Packing Method Tray
Terminal Finish Tin (Sn)
Resistance 150mOhm
ECCN Code EAR99
Termination Radial
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 5%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 115.000011g
Number of Pins 4
Terminal Shape WIRE
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
