B82615B2102M001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) 1 INDUCTANCE IS MEASURED AT 0.1MILLI AMPERE Common Mode Choke 1A 3Ohm 0.01MHz 44mm
PDF
/
Buying Options
Total Price: USD $7.55
Unit Price: USD $7.5504
≥1 USD $7.5504
≥10 USD $6.73112
≥100 USD $6.322976
≥500 USD $6.11908
≥1000 USD $5.81306
≥3000 USD $5.711094
Inventory: 225
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Through Hole
Terminal Shape WIRE
Number of Pins 4
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Tolerance 20%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
ECCN Code EAR99
Resistance 3Ohm
Terminal Finish Tin (Sn)
Packing Method Tray
Shielding NO
Number of Functions 1
Depth 42.4mm
Construction Rectangular
Current Rating 1A
Military Standard Not
Lead Pitch 40mm
Operating Temperature (Max) 125°C
Inductance 20 mH
Test Frequency 0.01MHz
Max DC Current 1A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 3Ohm
Inductance Tolerance 20%
Inductance-Nom (L) 20000 μH
DC Current 1A
Special Feature INDUCTANCE IS MEASURED AT 0.1 MILLI AMPERE
Dimensions
Length 44mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
