B82614R2242A030
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) 1 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 2.4A 1.52Ohm 100kHz 32.5mm
PDF
/
Inventory: 2352
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 32.5mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
DC Current 2.4A
Inductance-Nom (L) 750 μH
Inductance Tolerance 30%
DC Resistance (DCR) - Parallel 1.52Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Test Frequency 100kHz
Inductance 750 μH
Operating Temperature (Max) 125°C
Lead Pitch 15mm
Military Standard Not
Current Rating 2.4A
Construction Rectangular
Depth 21mm
Number of Functions 1
Shielding NO
Packing Method Tray
Terminal Finish Tin (Sn)
Resistance 330mOhm
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 4
Terminal Shape WIRE
Surface Mount NO
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
