B82614R2202A030
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) 1 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 2A 1.52Ohm 100kHz 32.5mm
PDF
/
Buying Options
Total Price: USD $6
Unit Price: USD $6.003818
≥1 USD $6.003818
≥10 USD $5.663982
≥100 USD $5.343378
≥500 USD $5.040919
≥1000 USD $4.755582
Inventory: 1164
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 32.5mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
DC Current 2A
Inductance-Nom (L) 1000 μH
Inductance Tolerance 30%
Rated Current-Max 2A
DC Resistance (DCR) - Parallel 1.52Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Test Frequency 100kHz
Inductance 1 mH
Operating Temperature (Max) 125°C
Lead Pitch 15mm
Military Standard Not
Current Rating 2A
Construction Rectangular
Depth 21mm
Number of Functions 1
Shielding NO
Packing Method Tray
Terminal Finish Tin (Sn)
Resistance 430mOhm
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 4
Terminal Shape WIRE
Surface Mount NO
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
