B82504WA3
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Nickel (Ni) 2 INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT IRON-SILICON Common Mode Choke 4A 330mOhm 0.01MHz 77.978mm
PDF
/
Inventory: 2843
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 27.94mm
Length 77.978mm
Height 37.0078mm
Technical
Current Rating (Max) 4A
Number of Lines 2
Special Feature INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT
Inductance-Nom (L) 2000 μH
DC Resistance (DCR) - Parallel 330mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Screw
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 4A
Test Frequency 0.01MHz
Inductance 2 mH
Operating Temperature (Min) -40°C
Voltage - Rated AC 500V
Depth 28mm
Number of Functions 1
Shielding NO
Voltage - Rated DC 600V
HTS Code 8504.50.80.00
Terminal Finish Nickel (Ni)
ECCN Code EAR99
Pbfree Code yes
Tolerance 20%
Physical
Core Material IRON-SILICON
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape BINDING POST
Mount Chassis Mount
