B82504W0000A005
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Power Line Choke 200uH 20% 100KHz 10A 54mOhm DCR Screw Box
PDF
/
Inventory: 9159
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 78mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1MA DC CURRENT
DC Current 10A
Inductance-Nom (L) 200 μH
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Test Frequency 100kHz
Inductance 200 μH
Operating Temperature (Min) -40°C
Military Standard Not
Current Rating 10A
Construction Rectangular Case
Depth 28mm
Number of Functions 1
Shielding NO
Packing Method Cardboard
HTS Code 8504.50.80.00
Resistance 54mOhm
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
Tolerance 20%
Packaging Box
Physical
Core Material IRON-SILICON
Shape/Size Description RECTANGULAR PACKAGE
Number of Pins 2
Terminal Shape BINDING POST
Mount Screw
Contact Plating Nickel
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 month ago)
