B82502WC5
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tin (Sn) 2 e3 IRON-SILICON Common Mode Choke 500mA 8.5Ohm 50.0126mm 15mH
PDF
/
Inventory: 9563
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 22.5044mm
Length 50.0126mm
Height 13.0048mm
Technical
Current Rating (Max) 500mA
Number of Lines 2
Inductance-Nom (L) 15000 μH
DC Resistance (DCR) - Parallel 8.5Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Radial
Inductor Application POWER INDUCTOR
Max DC Current 500mA
Inductance 15 mH
Operating Temperature (Min) -40°C
Voltage - Rated AC 500V
Depth 22.5mm
Number of Functions 1
Shielding NO
Voltage - Rated DC 600V
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e3
Tolerance 20%
Physical
Core Material IRON-SILICON
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape SOLID LEAD
Mount Through Hole
