CMT4-1-R
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes / Filters 5.4 mH
PDF
/
Buying Options
Total Price: USD $23.47
Unit Price: USD $23.468088
≥1 USD $23.468088
≥224 USD $9.364916
≥448 USD $9.051133
≥1008 USD $8.89621
Inventory: 5350
Minimum: 1
-
+
Technical Details
Technical
Number of Lines 2
DC Resistance (DCR) (Max) 120mOhm Typ
Current Rating (Max) 2A
Inductance @ Frequency 5.4mH @ 10kHz
Filter Type Power Line
Lead/Base Style Pin
Max DC Current 2A
Current 2A
Test Frequency 10kHz
Inductance 5.4 mH
Depth 15.4mm
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 120mOhm
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.984Lx0.606W 25.00mmx15.40mm
Series CMT
Published 2015
Packaging Bulk
Operating Temperature -40°C~125°C
Dimensions
Height 25.5mm
Length 24.9936mm
Width 15.3924mm
Height (Max) 1.004 25.50mm
Physical
Core Material Ferrite
Weight 453.59237mg
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
