CMT3-3-R
RoHS
/
Package Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes / Filters 2.7 mH
PDF
/
Buying Options
Total Price: USD $22.54
Unit Price: USD $22.537241
≥1 USD $22.537241
≥140 USD $8.993365
≥560 USD $8.692711
≥980 USD $8.544353
Inventory: 4171
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height (Max) 0.551 14.00mm
Width 24.9936mm
Length 24.9936mm
Height 13.9954mm
Diameter 25mm
Technical
Inductance @ Frequency 2.7mH @ 10kHz
Current Rating (Max) 3A
DC Resistance (DCR) (Max) 55mOhm Typ
Number of Lines 2
DC Current 3A
Filter Type Power Line
Lead/Base Style Pin
Max DC Current 3A
Current 3A
Test Frequency 10kHz
Inductance 2.7 mH
Military Standard Not
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.984Lx0.984W 25.00mmx25.00mm
Series CMT
Published 2015
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Core Material Ferrite
Weight 12.700586g
Package / Case Horizontal, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
