CMT2-7-R
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes / Filters 3.2 mH
PDF
/
Buying Options
Total Price: USD $23.89
Unit Price: USD $23.88559
≥1 USD $23.88559
≥240 USD $9.530341
≥480 USD $9.212619
≥960 USD $9.055071
Inventory: 6192
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Weight 453.59237mg
Core Material Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Published 2015
Series CMT
Size / Dimension 1.437Lx1.043W 36.50mmx26.50mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
Resistance 42mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Shielding Unshielded
Depth 26.5mm
Inductance 3.2 mH
Test Frequency 10kHz
Current 4.4A
Max DC Current 4.4A
Lead/Base Style Pin
Filter Type Power Line
Number of Lines 2
DC Resistance (DCR) (Max) 42mOhm Typ
Current Rating (Max) 4.4A
Inductance @ Frequency 3.2mH @ 10kHz
Dimensions
Height 44.5mm
Length 36.4998mm
Width 26.4922mm
Height (Max) 1.752 44.50mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
