CMT2-3-R
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes / Filters 12 mH
PDF
/
Buying Options
Total Price: USD $23.89
Unit Price: USD $23.88559
≥1 USD $23.88559
≥240 USD $9.530341
≥480 USD $9.212619
≥960 USD $9.055071
Inventory: 3981
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height (Max) 1.752 44.50mm
Width 26.4922mm
Length 36.4998mm
Height 44.5mm
Technical
Inductance @ Frequency 12mH @ 10kHz
Current Rating (Max) 2.45A
DC Resistance (DCR) (Max) 135mOhm Typ
Number of Lines 2
Filter Type Power Line
Lead/Base Style Pin
Max DC Current 2.45A
Current 2.45A
Test Frequency 10kHz
Inductance 12 mH
Depth 26.5mm
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 135mOhm
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 1.437Lx1.043W 36.50mmx26.50mm
Series CMT
Published 2007
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Core Material Ferrite
Weight 453.59237mg
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
