CMS3-8-R
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 350uH 100kHz 2A SMD T/R
PDF
/
Buying Options
Total Price: USD $4.74
Unit Price: USD $4.7432
≥1 USD $4.7432
≥10 USD $3.84296
≥100 USD $3.415808
≥500 USD $3.22608
≥1000 USD $2.98892
≥3000 USD $2.941453
Inventory: 919
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Number of Pins 4
Weight 2.267962g
Core Material Ferrite
Technical
Operating Temperature -40°C~160°C
Packaging Tape & Reel (TR)
Published 2007
Series CMS
Size / Dimension 0.450Lx0.450W 11.43mmx11.43mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Max Operating Temperature 160°C
Min Operating Temperature -40°C
Shielding Unshielded
Depth 13.97mm
Current Rating 2A
Military Standard Not
Inductance 350 μH
Test Frequency 100kHz
Current 2A
Max DC Current 2A
Filter Type Power Line
DC Current 2A
Number of Lines 2
DC Resistance (DCR) (Max) 40mOhm Typ
Current Rating (Max) 2A
Inductance @ Frequency 350μH @ 100kHz
Dimensions
Height 5.9944mm
Length 13.97mm
Width 13.97mm
Height (Max) 0.236 6.00mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
