CMS2-4-R image
Favorite
CMS2-4-R image
Favorite
RoHS
RoHS RoHS compliant
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 102uH 100kHz 2.8A SMD T/R
PDF
/
Buying Options
Total Price: USD $3.26
Unit Price: USD $3.256
≥1 USD $3.256
≥10 USD $2.72008
≥100 USD $2.483712
≥500 USD $2.12872
≥1000 USD $1.9514
≥3000 USD $1.892282
Inventory: 1175
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Number of Pins 4
Weight 1.360777g
Core Material Ferrite

Technical

Operating Temperature -40°C~160°C
Packaging Tape & Reel (TR)
Published 2007
Series CMS
Size / Dimension 0.350Lx0.350W 8.90mmx8.90mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 19mOhm
Max Operating Temperature 160°C
Min Operating Temperature -40°C
Shielding Unshielded
Depth 11.43mm
Current Rating 2.8A
Military Standard Not
Inductance 102 μH
Test Frequency 100kHz
Element Configuration Dual
Current 2.8A
Max DC Current 2.8A
Filter Type Power Line
DC Current 2.8A
Number of Lines 2
DC Resistance (DCR) (Max) 19mOhm Typ
Current Rating (Max) 2.8A
Inductance @ Frequency 102μH @ 100kHz

Dimensions

Height 6mm
Length 11.43mm
Width 11.43mm
Height (Max) 0.236 6.00mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
