CMS2-14-R
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
INDUCTOR COMMON MODE 1340UH SMD
PDF
/
Buying Options
Total Price: USD $3.64
Unit Price: USD $3.6432
≥1 USD $3.6432
≥10 USD $3.04656
≥100 USD $2.781504
≥500 USD $2.384096
≥1000 USD $2.185392
≥3000 USD $2.119146
Inventory: 1187
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.236 6.00mm
Width 11.43mm
Length 11.43mm
Height 5.9944mm
Technical
Inductance @ Frequency 1.34mH @ 100kHz
Current Rating (Max) 500mA
DC Resistance (DCR) (Max) 620mOhm Typ
Number of Lines 2
DC Current 500mA
Filter Type Power Line
Max DC Current 500mA
Current 500mA
Test Frequency 100kHz
Inductance 1.34 mH
Military Standard Not
Depth 11.43mm
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 160°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.350Lx0.350W 8.90mmx8.90mm
Series CMS
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~160°C
Physical
Core Material Ferrite
Weight 1.360777g
Number of Pins 4
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
