CMS2-10-R
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
INDUCTOR COMMON MODE 575UH SMD
PDF
/
Buying Options
Total Price: USD $3.85
Unit Price: USD $3.8456
≥1 USD $3.8456
≥10 USD $3.21816
≥100 USD $2.938496
≥500 USD $2.51856
≥1000 USD $2.30868
≥3000 USD $2.23872
Inventory: 874
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.236 6.00mm
Width 11.43mm
Length 11.43mm
Height 5.9944mm
Technical
Inductance @ Frequency 575μH @ 100kHz
Current Rating (Max) 940mA
DC Resistance (DCR) (Max) 170mOhm Typ
Number of Lines 2
DC Current 940mA
Filter Type Power Line
Max DC Current 940mA
Current 940mA
Test Frequency 100kHz
Inductance 575 μH
Military Standard Not
Current Rating 940mA
Depth 11.43mm
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 160°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.350Lx0.350W 8.90mmx8.90mm
Series CMS
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~160°C
Physical
Core Material Ferrite
Weight 1.360777g
Number of Pins 4
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
