CMS1-3-R image
Favorite
CMS1-3-R image
Favorite
RoHS
RoHS RoHS compliant
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description CMC 12.6UH 4.1A 2LN SMD
PDF
/
Buying Options
Total Price: USD $2.62
Unit Price: USD $2.6224
≥1 USD $2.6224
≥10 USD $2.19648
≥100 USD $2.005696
≥500 USD $1.719168
≥1000 USD $1.575904
≥3000 USD $1.528138
Inventory: 1500
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Height (Max) 0.102 2.60mm
Width 7.1882mm
Length 9.4mm
Height 2.6mm

Technical

Inductance @ Frequency 12.6μH @ 100kHz
Current Rating (Max) 4.1A
DC Resistance (DCR) (Max) 77mOhm
Number of Lines 2
DC Current 4.1A
Filter Type Power Line
Max DC Current 4.1A
Current 4.1A
Test Frequency 100kHz
Inductance 12.6 μH
Military Standard Not
Current Rating 4.1A
Depth 7.2mm
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 160°C
Resistance 7.7mOhm
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.370Lx0.283W 9.40mmx7.20mm
Series CMS
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~160°C

Physical

Core Material Ferrite
Weight 453.59237mg
Number of Pins 4
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 15 Weeks
