CMS1-10-R image
Favorite
CMS1-10-R image
Favorite
RoHS
RoHS RoHS compliant
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 73.7uH 100kHz 1.65A 48mOhm DCR SMD T/R
PDF
/
Buying Options
Total Price: USD $2.59
Unit Price: USD $2.5872
≥1 USD $2.5872
≥10 USD $2.1956
≥100 USD $2.023296
≥500 USD $1.808048
≥1000 USD $1.506648
≥3000 USD $1.463651
Inventory: 1153
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Height (Max) 0.102 2.60mm
Width 7.1882mm
Length 9.4mm
Height 2.6mm

Technical

Inductance @ Frequency 73.7μH @ 100kHz
Current Rating (Max) 1.65A
DC Resistance (DCR) (Max) 48mOhm Typ
Number of Lines 2
DC Current 1.65A
Filter Type Power Line
Max DC Current 1.65A
Current 1.65A
Test Frequency 100kHz
Inductance 73.7 μH
Military Standard Not
Depth 7.2mm
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 160°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.370Lx0.283W 9.40mmx7.20mm
Series CMS
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~160°C

Physical

Core Material Ferrite
Weight 453.59237mg
Number of Pins 4
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 15 Weeks
