CMS1-1-R
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 4.5uH 100kHz 7A 2.7mOhm DCR SMD T/R
PDF
/
Buying Options
Total Price: USD $4.31
Unit Price: USD $4.312
≥1 USD $4.312
≥10 USD $3.608
≥100 USD $3.294368
≥500 USD $2.823744
≥1000 USD $2.588432
≥3000 USD $2.509971
Inventory: 1361
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Number of Pins 4
Weight 453.59237mg
Core Material Ferrite
Technical
Operating Temperature -40°C~160°C
Packaging Tape & Reel (TR)
Published 2005
Series CMS
Size / Dimension 0.370Lx0.283W 9.40mmx7.20mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 2.7mOhm
Max Operating Temperature 160°C
Min Operating Temperature -40°C
Shielding Unshielded
Depth 7.2mm
Current Rating 7A
Military Standard Not
Inductance 4.5 μH
Test Frequency 100kHz
Element Configuration Dual
Current 7A
Max DC Current 7A
Filter Type Power Line
DC Current 7A
Number of Lines 2
DC Resistance (DCR) (Max) 2.7mOhm Typ
Self Resonant Frequency 100MHz
Current Rating (Max) 7A
Inductance @ Frequency 4.5μH @ 100kHz
Dimensions
Height 2.6mm
Length 9.4mm
Width 7.1882mm
Height (Max) 0.102 2.60mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
