E3500-AL

Coilcraft
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
PDF
/
Inventory: 3276
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Width 27.94mm
Length 27.94mm
Height 30.48mm

Technical

DC Resistance (DCR) (Max) 0.5Ohm
Rated Current 0.75A
Filter Type DATA LINE FILTER
Inductance 6600 μH
Operating Temperature (Min) -40°C
Physical Dimension L27.94XB27.94XH30.48 (mm)/L1.1XB1.1XH1.2 (inch)
Operating Temperature (Max) 85°C
Approval Agency UL; VDE
Number of Functions 2
HTS Code 8504.50.80.00
Additional Feature TIN-SILVER OVER TIN OVER COPPER TERMINATION
Terminal Finish Tin/Silver (Sn/Ag)
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e2

Physical

Mounting Type THROUGH HOLE MOUNT

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 hours ago)
