SRF2012-900YA
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
CMC 400MA 2LN 90 OHM SMD
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
≥10 USD $0.2684
≥100 USD $0.247808
≥500 USD $0.22704
≥1000 USD $0.2002
≥3000 USD $0.194022
Inventory: 1260
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Material Steel
Core Material Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2006
Series SRF2012A
Size / Dimension 0.079Lx0.047W 2.00mmx1.20mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 90Ohm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8504.50.80.00
Voltage - Rated DC 50V
Packing Method TAPE AND REEL
Shielding Unshielded
Number of Functions 2
Depth 1.4mm
Current Rating 400mA
Base Part Number SRF2012
Insulation Resistance 10MOhm
Test Frequency 100MHz
Impedance 90Ohm
Element Configuration Dual
Current 400mA
Max DC Current 400mA
Halogen Free Halogen Free
Filter Type DATA LINE FILTER
DC Current 400mA
Number of Lines 2
DC Resistance (DCR) (Max) 300mOhm
Impedance @ Frequency 90Ohm @ 100MHz
Dimensions
Height 1.2mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
