DR331-105BE

Bourns Inc.
RoHS
RoHS RoHS compliant
Package Horizontal, 4 Flat Lead
Category Filters / Common Mode Chokes
Description Common Mode Filters / Chokes 1000uH 25%
PDF
/
Buying Options
Total Price: USD $0.65
Unit Price: USD $0.6512
≥1 USD $0.6512
≥10 USD $0.5544
≥100 USD $0.504064
≥500 USD $0.473968
≥1000 USD $0.393272
≥3000 USD $0.363018
Inventory: 44930
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Length 7.3mm
Height 4.7mm

Technical

Inductance @ Frequency 1mH @ 100kHz
Rated Voltage 80V
DC Resistance (DCR) (Max) 400mOhm
Number of Lines 2
DC Current 500mA
Inductance Tolerance 25%
Filter Type Signal Line
Max DC Current 500mA
Current 500mA
Test Frequency 100kHz
Inductance 1 mH
Lead Pitch 3.7mm
Approval Agency UL
Voltage - Rated AC 42V
Military Standard Not
Current Rating 500mA
Depth 9.3mm
Number of Functions 2
Packing Method TAPE AND REEL
Voltage - Rated DC 80V
Additional Feature TAPE AND REEL
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.287Lx0.213W 7.30mmx5.40mm
Series DR331
Published 2006
Packaging Cut Tape (CT)
Operating Temperature -40°C~135°C

Physical

Core Material Ferrite
Number of Pins 4
Package / Case Horizontal, 4 Flat Lead
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 18 Weeks
