8119
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 4MH 14.5A 2LN TH
PDF
/
Buying Options
Total Price: USD $16.47
Unit Price: USD $16.469018
≥1 USD $16.469018
≥224 USD $6.572377
≥504 USD $6.35181
≥1008 USD $6.244152
Inventory: 4416
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 41.91mm
Technical
Inductance @ Frequency 4mH @ 1kHz
DC Resistance (DCR) (Max) 12mOhm
Number of Lines 2
DC Current 14.5A
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application HIGH CURRENT INDUCTOR
Current 14.5A
Test Frequency 1kHz
Inductance 4 mH
Lead Pitch 30.48mm
Military Standard Not
Depth 23.11mm
Number of Functions 2
Shielding NO
HTS Code 8504.50.80.00
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 1.700Lx0.900W 43.18mmx22.86mm
Series 8100
Packaging Tray
Operating Temperature -55°C~105°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WIRE
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
