7516-RC
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 30MH 800MA 2LN TH
PDF
/
Buying Options
Total Price: USD $2.51
Unit Price: USD $2.514204
≥1 USD $2.514204
≥200 USD $0.974172
≥500 USD $0.940036
≥1200 USD $0.922969
Inventory: 2164
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2009
Series 7500
Size / Dimension 0.906Lx0.748W 23.00mmx19.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
HTS Code 8504.50.80.00
Number of Functions 2
Depth 19mm
Military Standard Not
Voltage - Rated AC 250V
Approval Agency UL
Lead Pitch 13mm
Inductance 30 mH
Test Frequency 1kHz
Element Configuration Dual
Current 800mA
Max DC Current 800mA
Lead/Base Style Pin
Filter Type Power Line
DC Current 800mA
Number of Lines 2
DC Resistance (DCR) (Max) 760mOhm
Inductance @ Frequency 30mH @ 1kHz
Dimensions
Height 27.5082mm
Compliance
RoHS Status ROHS3 Compliant
