7402-RC
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 600uH 1kHz 2.8A 46mOhm DCR Thru-Hole
PDF
/
Inventory: 996
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
HTS Code 8504.50.80.00
Number of Functions 2
Depth 17mm
Military Standard Not
Voltage - Rated AC 250V
Approval Agency UL
Lead Pitch 13mm
Inductance 600 μH
Test Frequency 1kHz
Element Configuration Dual
Current 2.8A
Max DC Current 2.8A
Lead/Base Style Pin
Filter Type Power Line
DC Current 2.8A
Number of Lines 2
DC Resistance (DCR) (Max) 46mOhm
Inductance @ Frequency 600μH @ 1kHz
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.748Lx0.669W 19.00mmx17.00mm
Series 7400
Published 2009
Packaging Bulk
Operating Temperature -55°C~105°C
Dimensions
Height 21.0058mm
Length 19mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 18 Weeks
