RoHS
/
Package Vertical, No Base, 2 PC Pin
Category Filters / Common Mode Chokes
Description COMMON MODE CHOKE 5MH 4A 2LN TH
PDF
/
Inventory: 8109
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, No Base, 2 PC Pin

Technical

Operating Temperature -55°C~105°C
Packaging Bulk
Series 7100
Size / Dimension 1.200Diax0.800W 30.48mmx20.32mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Base Part Number 7100
Inductance 5 mH
Current 4A
Number of Lines 2
DC Resistance (DCR) (Max) 46mOhm
Current Rating (Max) 4A
Inductance @ Frequency 5mH @ 1kHz

Dimensions

Length 20.3mm
Width 20.32mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
