7104
RoHS
/
Package Vertical, No Base, 2 PC Pin
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 3MH 1A 2LN TH
PDF
/
Inventory: 6645
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 11.43mm
Length 11.4mm
Technical
Inductance @ Frequency 3mH @ 1kHz
Current Rating (Max) 1A
DC Resistance (DCR) (Max) 100mOhm
Number of Lines 2
Current 1A
Inductance 3 mH
Base Part Number 7100
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.600Diax0.450W 15.24mmx11.43mm
Series 7100
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Package / Case Vertical, No Base, 2 PC Pin
Mounting Type Through Hole
Mount Through Hole
