3000-221
RoHS
/
Package Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
3000 Horizontal 4PC Pin 2 Signal Line Common Mode Choke 790mA 316mOhm 1kHz 0.490Lx0.490W 12.45mmx12.45mm
PDF
/
Inventory: 4678
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 10.16mm
Technical
Inductance @ Frequency 220μH @ 1kHz
DC Resistance (DCR) (Max) 316mOhm
Number of Lines 2
Filter Type Signal Line
Max DC Current 790mA
Current 790mA
Test Frequency 1kHz
Inductance 220 μH
Reach Compliance Code unknown
Number of Functions 2
Shielding Unshielded
HTS Code 8504.50.80.00
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance 15%
Size / Dimension 0.490Lx0.490W 12.45mmx12.45mm
Series 3000
Published 2001
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Package / Case Horizontal, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
