CM9900R-683
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 68UH 3.5A 2LN TH
PDF
/
Buying Options
Total Price: USD $16.78
Unit Price: USD $16.776236
≥1 USD $16.776236
≥200 USD $6.694477
≥500 USD $6.471284
≥1000 USD $6.359688
Inventory: 8114
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 16.9926mm
Technical
Inductance @ Frequency 68μH @ 1kHz
DC Resistance (DCR) (Max) 19mOhm
Number of Lines 2
Filter Type DATA LINE FILTER
Lead/Base Style Pin
Max DC Current 3.5A
Current 3.5A
Inductance 68 μH
Depth 18.8mm
Number of Functions 2
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.839Lx0.740W 21.30mmx18.80mm
Series CM9900R
Published 2010
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
