CM7560R-686
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 68MH 270MA 2LN TH
PDF
/
Buying Options
Total Price: USD $64.17
Unit Price: USD $64.1693
≥1 USD $64.1693
≥200 USD $25.604176
≥500 USD $24.749478
≥1000 USD $24.326724
Inventory: 1559
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 21.8694mm
Technical
Inductance @ Frequency 68mH @ 1kHz
DC Resistance (DCR) (Max) 5Ohm
Number of Lines 2
Filter Type DATA LINE FILTER
Lead/Base Style Pin
Max DC Current 270mA
Current 270mA
Inductance 68 mH
Depth 28.47mm
Number of Functions 2
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 1.071Lx0.858W 27.20mmx21.80mm
Series CM7560R
Published 2010
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
