CM7560R-154
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 150UH 5.5A 2LN TH
PDF
/
Buying Options
Total Price: USD $43.66
Unit Price: USD $43.657864
≥1 USD $43.657864
≥200 USD $17.419557
≥500 USD $16.837943
≥1000 USD $16.550417
Inventory: 3624
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 21.8694mm
Technical
Inductance @ Frequency 150μH @ 1kHz
DC Resistance (DCR) (Max) 15mOhm
Number of Lines 2
Filter Type DATA LINE FILTER
Lead/Base Style Pin
Max DC Current 5.5A
Current 5.5A
Inductance 150 μH
Depth 28.47mm
Number of Functions 2
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 1.071Lx0.858W 27.20mmx21.80mm
Series CM7560R
Published 2010
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
